LED VMS Electronic Traffic Signs Wireless Controlled Changeable Message
Product Details:
| Place of Origin: | Shenzhen, China |
| Brand Name: | YAHAM |
| Certification: | EN12966、NTCIP |
| Model Number: | YHT-VMS-OT25 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 25 Square Meter/Square Meters |
|---|---|
| Price: | $1200-2350 Square Meter/Square Meters |
| Packaging Details: | WOODEN CASE |
| Delivery Time: | 22 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 4180 Square Meter/Square Meters Per Month |
|
Detail Information |
|||
| Pixels: | 25mm | LED Brand: | Nichia, Cree, Nationstar, Unionled |
|---|---|---|---|
| Power Supply: | 110-240V AC | Signal Transfer: | Cat 5 Network Cable, RS232,RS485 Optional |
| Max. Power Consumption: | 220W/m² | Store Humidity: | 15%~ 95% |
| High Light: | LED VMS Electronic Traffic Signs,P25 Electronic Traffic Signs,VMS LED Changeable Message Signs |
||
Product Description
LED VMS Electronic Traffic Signs Wireless Controlled Changeable Message
Wireless Controlled LED VMS Signs Outdoor LED Traffic Information System
Variable Message Signs (VMS) are quite commonly used for the traffic warning information of road & bridge construction, fire-fighting, parking lots, etc. The high brightness and strong eye-catching LED technology deliver the traffic information to the driver, remind them to focus on their driving speed and pay attention to the weather, road situation, and so on. It can reduce the traffic accident by deploying the road traffic management.
Designed and manufactured by YAHAM, the cost effective and P10/P16/P20/P25 Road Side Led Digital Billboard Truck Mounted Folding Traffic Message Car LED VMS Display can play any range of text message,graphics and animations in high visibility color. You can design your own symbols, corporate logos and more.The road side traffic message signs are popular for using in traffic management and advertisement.
Application:
It is widely used in highway tunnel, urban road, dense section of road network of main trunk line, urban road, street, airport, wharf, station and other traffic guidance and related application fields.
Minimized power consumption
When a screen is displaying message, for most cases, a large proportion of screen maintain black, Our product is able to detect it and turn this area into sleeping mode .
Second optical lens
It is well know that vms upper viewing angle makes light pollution 505 loss, By applying second lens, we can manufacture 0 ipper viewing angle 0 light pollutions and 0 energy loss
Lighting shock procetion
We have equipped lighting shock component of industrial level, High quality components include direct-lighting proctection, signal protection. power surge protections
Dual voltage Input
Due to lighting chip difference, red/amber led has lower threshold voltage to light up than green/blue LED,so we applied dual voltage chhannel to drive two types of LEDS, surplus enrgy is saved by this technology
Large storage memory
The build-in flash emory can strores as many as 2000 images and characters at a time
High Ingress protection
Our cabinet is fully sealed to enure ingress protection level up to IP65
Automatic/manual brightness control
Our digital photo sensor supports as many as 256 dimming levels with outside luminace range from 1 lx to 65535lx,which enables our display screen to adjust to appropriate luminance level according to outside environment luminance reading will also be reported to traffic control center
| Item | YHT-VMS-OT20 | YHT-VMS-OT25 | YHT-VMS-OT31.25 |
| Pixel pitch | 20mm | 25mm | 31.25mm |
| LED type | 3 in1 SMD+lens | 3 in1 SMD+lens | 3 in1 SMD+lens |
| Pixel density | 2500 pixels/m² | 1600 pixels/m² | 1024 pixels/m² |
| Module dimension | 320×160 mm | 200×200 mm | 250×250 mm |
| Module resolution | 16×8 | 8×8 | 8×8 |
| Cabinet material | 2mm aluminum Alloy | ||
| Screen weight | 65kg/m² | ||
| Cabinet dimension | 960×960 mm | 1000×1000 mm | 1000×1000 mm |
| Brightness | L3,L3*:EN12966 (Red: >3100nits, Green>3720nits, Blue>1240nits, Amber>7440nits, White:>12400nits) | ||
| Brightness adjustment | 32/256 | ||
| Color coordinates | C2: EN12966 | C2: EN12966 | C2: EN12966 |
| Refresh rate | >90+ Hz | >90+ Hz | >90+ Hz |
| Display control | Asynchronous control system available | ||
| Display capacity | Text, image, graphics animations | ||
| Lifespan | >100000 hrs | >100000 hrs | >100000 hrs |
| Power supply | 12-24V DC/110-230V AC | ||
| Max. Power consumption | 220W/m² | 220W/m² | 220W/m² |
| Avg. Power consumption | 70W/m² | 70W/m² | 70W/m² |
| Operation temperature | -25~ +60°C | ||
| Storage temperature | -40~ +80°C | ||
| Store humidity | 15%~ 95% | 15%~ 95% | 15%~ 95% |
| Protection level | IP56(P3:12966) | IP56(P3:12966) | IP56(P3:12966) |
| Maintenance method | Rear service | Rear service | Rear service |
| EN12966 | compliance | compliance | compliance |
