Full Color LED VMS Signs High Brightness Traffic Guidance Display

Full Color LED VMS Signs High Brightness Traffic Guidance Display

Product Details:

Place of Origin: Shenzhen, China
Brand Name: YAHAM
Certification: EN12966、NTCIP
Model Number: YHT-VMS-OT10

Payment & Shipping Terms:

Minimum Order Quantity: 20 Square Meter/Square Meters
Price: $1200-2300 Square Meter/Square Meters
Packaging Details: WOODEN CASE
Delivery Time: 15 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 4280 Square Meter/Square Meters Per Month
Get Best Price Contact Now

Detail Information

Pixels: 10mm Pixel Density: 10000 Pixels/m²
Module Dimension: 320×160 Mm Module Resolution: 32×16
Driving Method: 2S Contrast Ratio: R2: EN12966
High Light:

LED VMS Signs

,

VMS P10 LED Sign

,

P10mm High Brightness LED Display

Product Description

Full Color LED VMS Signs High Brightness Traffic Guidance Display



Traffic Guidance Full Color High Brightness LED Display P10 VMS Sign



Integrate that latest manufacture technology and combining the patch manufacturing technology with the lens technology, the invention not only achieve the guarantee of the patch technology on the product stability, but also achieves the color mixing effect of the lens lamp bead.



YAHAM LED variable message signs and traffic guidanceequipment traffic information dissemination, which is based on LED lighting device shows the effect of the basic traffic information display unit of a display device with graphics and text. According to the instruction information traffic, weather and dispatching department, the operator can be released to the variable information boards of various notices and information to effectively induct traffic flow, improve transport capacity of the road network, the safety of the driver driving fast provide excellent service.



LED guidance screen is the product of the combination of intelligent transportation system and LED display technology. Its main role is to make real-time or delayed information transmission and road guidance for incoming traffic flow, and to intervene and manage traffic flow through advance information sharing. LED guidance screen has LED display of intelligence and operability, with the intelligent system of traffic guidance screen, can timely put forward early warning, road guidance and notification notification, etc.



Variable Message Signs (VMS) are quite commonly used for the traffic warning information of road & bridge construction, fire-fighting, parking lots, etc. The high brightness and strong eye-catching LED technology deliver the traffic information to the driver, remind them to focus on their driving speed and pay attention to the weather, road situation, and so on. It can reduce the traffic accident by deploying the road traffic management.



Designed and manufactured by YAHAM, the cost effective and P10/P16/P20/P25 Road Side Led Digital Billboard Truck Mounted Folding Traffic Message Car LED VMS Display can play any range of text message,graphics and animations in high visibility color. You can design your own symbols, corporate logos and more.The road side traffic message signs are popular for using in traffic management and advertisement.









Item YHT-VMS-OT10
Pixel pitch 10mm
LED type 3 in1 SMD+lens
Pixel density 10000 pixels/m²
Module dimension 320×160 mm
Module resolution 32×16
Cabinet material 2mm aluminum Alloy
Screen weight 65kg/m²
Cabinet dimension 960×960 mm
Brightness L3,L3*:EN12966 (Red: >3100nits, Green>3720nits, Blue>1240nits, Amber>7440nits, White:>12400nits)
Brightness adjustment 32/256
Color coordinates C2: EN12966
Refresh rate >90+ Hz
Display control Asynchronous control system available
Display capacity Text, image, graphics animations
Lifespan >100000 hrs
Power supply 12-24V DC/110-230V AC
Max. Power consumption 400W/m²
Avg. Power consumption 130W/m²
Operation temperature -25~ +60°C
Storage temperature -40~ +80°C
Store humidity 15%~ 95%
Maintenance method Rear service
EN12966 compliance
