12mm Fixed Motorway VMS Signs 3 in1 SMD lens Traffic Matrix display
Product Details:
| Place of Origin: | shenzhen，china |
| Brand Name: | YAHAM |
| Certification: | EN12966、NTCIP |
| Model Number: | YHT-OT12-1R1G1B |
Payment & Shipping Terms:
| Minimum Order Quantity: | 16 Square Meter/Square Meters |
|---|---|
| Price: | $1200-2000 Square Meter/Square Meters |
| Packaging Details: | POLY WOODEN CASE |
| Delivery Time: | 39 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 3200 Square Meter/Square Meters Per Month |
|
Detail Information |
|||
| Pixel Pitch: | 12mm | Screen Weight: | 65kg/m² |
|---|---|---|---|
| Customized Size: | 3-5 Years | Refresh Rate: | >90+ Hz |
| LED Type: | 3 In1 SMD+lens | Pixel Density: | 6944 Pixels/m² |
| Brightness Adjustment: | 32/256 | Signal Transfer: | Cat 5 Network Cable, RS232,RS485 Optional |
| Maintenance Method: | Rear Service | Store Humidity: | 15%~ 95% |
| High Light: | Fixed Motorway VMS Signs,12mm Motorway VMS Signs,EN12966 Led Matrix Signs |
||
Product Description
12mm Fixed Motorway VMS Signs 3 In1 SMD Lens Traffic Matrix Display
EN12966 vms fixed variable message sign traffic led motoways matrix signs lifespan >100000 hrs
Smart monitor
Yaham VMS can activate self-diagnosis and report health status, monitor can identify equipment health status, current message ID, current operating mode temperature, humidity, etc.
Global positioning system
Each VMS is paired with GPS, locations and VMS amount could be simply apparent to your eye.
Customized color
Yaham VMS is a highly customized product with color availability including monochrome,full-color and dual-color.
Yaham workshop covers 30,000 sq.m and owns a complete production line, including SMT, post-soldering, module assembly, gluing, burning, etc. Its capacity is over 5,000 sq.m per month.
YAHAM Optoelectronics' variable information signs have long service life, high brightness, low energy consumption, and are stable and durable under harsh conditions.
Provide high brightness, standard brightness and high density 3 kinds of modules, in line with various application requirements of LED variable intelligence board.
⊙The overall design of the structure with a downward slope of 4° ensures that the light normal is 250 meters away.
⊙A single point fault feedback system is built into the screen to ensure that the working status of the induction screen can be grasped at the first time in the control room.
| Item | YHT-VMS-OT10 | YHT-VMS-OT12 | YHT-VMS-OT16 |
| Pixel pitch | 10mm | 12mm | 16mm |
| LED type | 3 in1 SMD+lens | 3 in1 SMD+lens | 3 in1 SMD+lens |
| Pixel density | 10000 pixels/m² | 6944 pixels/m² | 3906 pixels/m² |
| Module dimension | 320×160 mm | 192×192 mm | 256×128 mm |
| Module resolution | 32×16 | 16×16 | 16×8 |
| Cabinet material | 2mm aluminum Alloy | ||
| Screen weight | 65kg/m² | ||
| Cabinet dimension | 960×960 mm | 960×960 mm | 1024×1024 mm |
| Brightness | L3,L3*:EN12966 (Red: >3100nits, Green>3720nits, Blue>1240nits, Amber>7440nits, White:>12400nits) | ||
| Brightness adjustment | 32/256 | ||
| Color coordinates | C2: EN12966 | C2: EN12966 | C2: EN12966 |
| Refresh rate | >90+ Hz | >90+ Hz | >90+ Hz |
| Display control | Asynchronous control system available | ||
| Display capacity | Text, image, graphics animations | ||
| Lifespan | >100000 hrs | >100000 hrs | >100000 hrs |
| Power supply | 12-24V DC/110-230V AC | ||
| Max. Power consumption | 400W/m² | 380W/m² | 250W/m² |
| Avg. Power consumption | 130W/m² | 120W/m² | 80W/m² |
| Operation temperature | -25~ +60°C | ||
| Storage temperature | -40~ +80°C | ||
| Store humidity | 15%~ 95% | 15%~ 95% | 15%~ 95% |
| Protection level | IP56(P3:12966) | IP56(P3:12966) | IP56(P3:12966) |
